Model 6485 Picoammeter Instruction Manual Buffer 6-3
Figure 6-1
Buffer locations
Recall
Perform the following steps to view stored readings and buffer statistics:
1. Press RECALL. The message RDG NO. 1 is displayed. Note that the arrow annun-
ciator (↔) also turns on to indicate that additional data is available for viewing.
2. Use the RANGE keys and , and the cursor keys and , to navigate through
the reading numbers and buffer statistics, reading values, and timestamps (shown
in Figure 6-1). For information on how to set buffer timestamps, see “Buffer times-
tamps,” page 6-4.
3. Press EXIT to return to the normal display.
RANGE
RANGE
RDG NO. 10 Reading Value Timestamp
RDG NO. 9 Reading Value Timestamp
RDG NO. 8 Reading Value Timestamp
RDG NO. 7 Reading Value Timestamp
RDG NO. 6 Reading Value Timestamp
RDG NO. 5 Reading Value Timestamp
RDG NO. 4 Reading Value Timestamp
RDG NO. 3 Reading Value Timestamp
RDG NO. 2 Reading Value Timestamp
RDG NO. 1 Reading Value Timestamp
STD DEV Standard Deviation Value ----------
AVERAGE Average Value ----------
PK-PK Peak to Peak Value ----------
MIN AT XX Minimum Value Timestamp
MAX AT XX Maximum Value Timestamp
g
STD DEV Standard Deviation Value
AVERAGE Average Value
PK-PK Peak to Peak Value
Buffer Statistics
Timestamp
Timestamp
Timestamp
Timestamp
Timestamp
Timestamp
Timestamp
Timestamp
Timestamp
Timestamp
----------
----------
----------
Timestamp
Timestamp
Buffer Timestamps
6485
PICOAMMETER
BUFFER
6485
PICOAMMETER
BUFFER
6485
PICOAMMETER
BUFFER
3 43 4
