Keysight B1505A User’s Guide, Edition 12 3-43
Accessories
Table 3-5 N1265A Status Indicator and Selector Connection Path
CAUTION Never connect the UHVU High terminal to any output, including circuit common,
chassis ground, or any other measurement resource such as SMU. Connecting other
measurement resource may damage the connected one.
CAUTION For the ultra high voltage measurement of active device, connect the UHVU High
terminal to the drain/collector terminal of a DUT. And for connecting the gate/base
terminal and the chuck terminal, use two SMU output terminals which are
connected to MCSMU and are attaching the N1265A-040 protection adapter. Then
connect a High terminal to the gate/base terminal, and the another High terminal to
the chuck terminal. And connect all three Low terminals to the source/emitter
terminal.
For the other cases, never connect any other measurement resource to the UHVU
Low terminal or the DUT terminal connected to it. Connecting other measurement
resource may damage the connected one.
Status
indicator
Selector Output terminals
Low Sense Low Force High Sense High Force
(off) Open Open Open Open
GNDU Sense GNDU Force Open Open
SMU GNDU Sense GNDU Force SMU Sense SMU Force
UHC UHCU Low Sense UHCU Low Force UHCU High Sense UHCU High Force
HVSMU
GNDU Sense GNDU Force HVSMU Force Open
GNDU Sense GNDU Force HVSMU Force
+ Series resistor
Open
