Getting Started
To Use Tracer Test Mode
To Use Tracer Test Mode
The following procedure performs the tracer test setup.
1. Click the Tracer Test tab on the main screen. The tab is in the leftmost column
on the screen. The I/V Trace screen is displayed. See Figure 1-4.
2. Set the channels at the field below the graph as shown in Table 1-1.
3. Set the measurement condition at the right field of the graph as shown in Table
1-3.
4. Set the graph display condition at the field below the graph as shown in Table
1-2.
To enter the value, use the USB keyboard or the screen/numeric keyboard opened by
clicking the right button of the entry field.
To start measurement, click for the single measurement or
for the repeat measurement.
If the Stop field is highlighted, the range of measurement and graph display can be
changed by using the rotary knob during the repeat measurement.
Table 1-1 I/V Trace Channel Setup
Table 1-2 I/V Trace Graph Setup
Unit V Name I Name
Mode
a
a. Channel output mode. Set I or IPULSE for the current output and volt-
age measurement. Set V or VPULSE for the voltage output and current
measurement.
Function
SMU1 V1 I1 V VAR1
SMU2 V2 I2 V CONST
Name Scale Name Scale
Y I1 LIN X V1 LIN
To Next Page
