5-46 Keysight B1505A User’s Guide, Edition 12
Measurement Examples
Using Multiple HVSMU Modules
Setting Output Range Mode
You can set the output range mode of the HVSMU by either of the following:
• Performing the HVSMUOP command using the classic test Direct Control
• Performing the setup using the application test Switch HVSMU Output Mode
For the HVSMUOP command, see Keysight B1500 Programming Guide.
The application test Switch HVSMU Output Mode belongs to the MultiHVSMU
category. For details of this application test, see the help message for each test
definition.
Performing Measurement
1. Open the application test Switch HVSMU Output Mode, and specify the output
range mode.
2. Click the Single button to set up the HVSMU output range mode.
3. Open the test definition or setup for a measurement, and specify the
measurement conditions.
4. Click the Single button to start the measurement.
Automation from the mode setup to the measurement is available by using the
Quick Test.
If the output setting in your test setup is over the output range of the specified mode,
the error 105001 occurs during the measurement. In this case, check the
measurement condition and set the output range mode and the condition properly.
Available Application Test List
Category Application Test Description
MultiHVSMU Switch HVSMU Output Mode Switching HVSMUs output range mode
