Keysight B1505A User’s Guide, Edition 12 5-43
Measurement Examples
Temperature Controlled by ThermoStream
10. Define the test setup execution order in the quick test.
Click the Quick Test tab on the main screen. The tab is in the leftmost column on
the screen.
The Quick Test screen lists the test setups created in steps 2 to 9.
If they are not listed according to the following order, change the order using the
Up/Down buttons.
a. ThermoStream Initialize (for initialization)
b. ThermoStream DefineParameters (for setting up the operation parameters)
c. ThermoStream ControlTemperature (for controlling the airflow temperature)
d. ThermoStream WaitTemperature or N1265A WaitTemperature (for waiting)
e. A device test setup
f. Repeating of steps c, d, and e
g. ThermoStream ControlTemperature (for ordinary temperature)
h. ThermoStream FlowOff (for stopping the airflow)
Performing Temperature Control and Measurement
1. Set your DUT into the N1271A-002 or -005 enclosure, and make the
connections.
2. Adjust the head position of the ThermoStream for the top cover surface of the
N1271A-002 or -005 enclosure, and then dock the ThermoStream with the
enclosure.
3. Click the Single button to start Quick Test. This opens the Data Display
window.
A temperature at the measurement is added to the Device ID.
WARNING Activating the Thermostream may cause low or high temperature of -50 °C to
+220 °C on the enclosure front panel, the cover, and the left and right
protection panels. To prevent yourself from getting injured, confirm that they
are in the safe temperature range before touching the enclosure.
