5-26 Keysight B1505A User’s Guide, Edition 12
Measurement Examples
I-V and Capacitance Measurements Using N1272A
Table 5-2 Connections for the IV Measurement
System Configuration and Open/Short Calibration
Select selector and measurement resources used for the measurement, and then
measure the Open and Short calibration data of all capacitance measurement paths
including the DUT interface as follows.
1. Click the Configuration button in the EasyEXPERT main window.
The Configuration window appears.
2. Click the Device Capacitance Selector tab to display the Device Capacitance
Selector tab screen.
3. Set up the Device Capacitance Selector and select the used measurement
resources.
NOTE To set up an I-V measurement using the IV path of the N1272A Device Capacitance
Selector, select IV in the Default Path field.
4. Click the Start Calibration... button to measure the calibration data of
measurement path. The Device Capacitance Calibration dialog box appears.
If you have measured and saved the calibration data of measurement path, click
the Select Calibration Data... button to select and load the stored calibration
data. Go to the step 7.
5. Click the Start button.
Follow the instruction displayed on the dialog to measure the open and short
calibration data.
It will take about 20 minutes to obtain the calibration data.
6. After finishing the calibration, click the Save and Apply button to save and apply
the calibration data.
7. Click the Close button to close the dialog box.
B1505A
Cable
N1265A
Output Terminal Input Terminal
GNDU GNDU Cable GNDU
Interlock Interlock Cable Interlock
To Next Page
