3-30 Keysight B1505A User’s Guide, Edition 12
Accessories
16493S-010/011 HCSMU Adapter
Adapters for HCSMU. The adapters are used with a DUT interface such as your
own test fixture and prober station, not the N1259A/N1265A test fixture.
16493S-010: Adapter for making the Kelvin connection of HCSMU path
16493S-011: Adapter for making the non-Kelvin connection of HCSMU path
•From HCSMU
Triaxial connector (Sense) and BNC connector (Force). For connecting 16493S
HCSMU cable from the HCSMU.
• Output of 16493S-010
• High Force/Sense
BNC connectors. Force and Sense must be extended to and connected
together at the high terminal of a DUT. For making the connection, use high
voltage cable with BNC(m) connector, manipulators, and such.
• Low Force/Sense
BNC connectors. Force and Sense must be extended to and connected
together at the low terminal of a DUT. For making the connection, use high
voltage cable with BNC(m) connector, manipulators, and such.
The DUT’s low terminal must be also connected to Force and Sense of the
GNDU. Use the N1261A-002/004 GNDU protection adapter.
• Output of 16493S-011
BNC connectors. High Force must be extended to the high terminal of a DUT.
Low Force must be extended to the low terminal of the DUT. For making the
connection, use high voltage cable with BNC(m) connector, manipulators, etc.
The DUT’s low terminal must be also connected to Force and Sense of the
GNDU. Use the N1261A-002/004 GNDU protection adapter.
NOTE Do not put any conductor on the HCSMU Low Force and Low Sense terminals,
outer conductor of the coaxial connectors. Putting conductor of circuit common,
chassis ground, or any potential on causes the measurement error.
