4-10 Keysight B1505A User’s Guide, Edition 12
Installation
Inspection and Installation
To Perform Initial Setup
After you receive the instrument, perform the following setup.
For the users available just after the initial setup, see Table 4-1.
1. Make sure that the Standby switch is set to off.
2. On the instrument rear panel, connect the Circuit Common terminal to the frame
ground terminal by using a shorting-bar.
3. If you use Keysight 16444A-001 USB keyboard and/or the 16444A-002 USB
mouse, connect it to an USB port of the instrument.
4. Connect the power cable from the instrument to an AC power outlet.
5. Open the measurement terminals and press the Standby switch to turn on the
instrument.
If the instrument is operating correctly, the power-on self-test is automatically
performed. If problems arise, see Keysight EasyEXPERT User’s Guide.
6. Follow the Windows setup wizard and complete the initial setup.
a. Set the system display language to English. The language must be English.
b. Set Country or region, Time and currency, and Keyboard layout.
If you use the 16444A-001 USB keyboard, the Keyboard layout must be US.
c. Accept the End User License Agreement.
d. Set Time zone, date and time.
If the instrument has been already connected to your site LAN, you can proceed
the network connection setup.
NOTE Other Windows setup
You can set other setup of Windows after the initial setup. It is your responsibility.
