Keysight B1505A User’s Guide, Edition 12 5-37
Measurement Examples
Temperature Controlled by Thermal Plate
If they are not listed according to the following order, change the order using the
Up/Down buttons.
a. ThermalPlate Initialize (for initialization)
b. ThermalPlate DefineParameters (for setting up the operation parameters)
c. ThermalPlate ControlTemperature (for controlling the temperature)
d. ThermalPlate WaitTemperature or N1265A WaitTemperature (for waiting)
e. A device test setup
f. Repeating of steps c, d, and e
g. ThermalPlate ControlTemperature (for ordinary temperature)
Performing Temperature Control and Measurement
1. Set your DUT on the thermal plate, and make the connections.
2. Set the hood of the N1271A-001 enclosure on the test fixture properly.
3. Click the Single button to start Quick Test. This opens the Data Display
window.
A temperature at the measurement is added to the Device ID.
WARNING The thermal plate may become high temperature up to +250 °C. To prevent
yourself from getting injured, confirm that it is in the safe temperature range
before touching it.
La plaque de température pourrait devenir la haute température à +250 degré
Celsius. D'être blessés avant de toucher la plaque confirmez s'il vous plaît que
deviennent la température sûre pour qu'il n'y ait pas cela.
