4-12 Keysight B1505A User’s Guide, Edition 12
Installation
Inspection and Installation
To Change GPIB Address
When this instrument is shipped from the factory, the GPIB address is set to 17. To
change the GPIB address, perform the following procedure.
1. If the EasyEXPERT software is running, terminate it as shown below:
a. Select the menu function File > Exit on the EasyEXPERT main screen.
b. Click [x] at the upper right corner of the Start EasyEXPERT button.
2. Select All Programs > Keysight IO Libraries Suite > Keysight Connection
Expert from the Start menu. Keysight Connection Expert window appears.
3. At the Instrument I/O on this PC area, select GPIB0, and click the Change
Properties... button. Keysight 82350 PCI GPIB Interface - GPIB0 window
appears.
4. Change the GPIB Address value.
5. Remove the check from the Auto-discover instruments connected to this
interface box.
6. Click the OK button on Keysight 82350 PCI GPIB Interface - GPIB0 window.
7. On the Reboot Required dialog box, click the Reboot Now button, and reboot
the instrument.
NOTE For the GPIB connection of this instrument, use an GPIB interface, Keysight
82350B (for PCI bus), Keysight 82357A/B (USB/GPIB), or National Instrument
GPIB-USB-HS.
For using an USB/GPIB interface, it is recommended to set the GPIB address of this
instrument to an even number. The USB/GPIB interface might cause serial poll error
intermittently due to the intrinsic communication scheme differences. It is reported
that using an even GPIB address sometimes significantly decreases the chance of
the error.
