Introduction
Measurement Resources
CAUTION Never connect the HVSMU Force and Guard terminals to any output, including
circuit common, chassis ground, or any other measurement resource such as SMU.
Connecting other measurement resource may damage the connected one.
Table 2-9 HVSMU Voltage Ranges and Resolutions
Table 2-10 HVSMU Current Ranges and Resolutions
Range
Output Value and
Measurement Value
Setting/
Measurement
Resolution
Maximum Current
|Imax|
200 V 0  |V|  200 V 200 V8 mA
500 V 0  |V|  500 V 500 V8 mA
1500 V 0  |V|  1500 V 1.5 mV 8 mA
3000 V 0  |V|  3000 V 3 mV 4 mA
Range
Output Value and
Measurement Value
Setting/
Measurement
Resolution
Maximum Voltage
|Vmax|
1 nA
a
a. DC only
0  |I|  1.15 nA 10 fA 3000 V
10 nA 0  |I|  11.5 nA 100 fA 3000 V
100 nA 0  |I|  115 nA 100 fA 3000 V
1 A0  |I|  1.15 A 1 pA 3000 V
10 A0  |I|  11.5 A 10 pA 3000 V
100 A0  |I|  115 A 100 pA 3000 V
1 mA 0  |I|  1.15 mA 1 nA 3000 V
10 mA 0  |I|  8 mA 10 nA 1500 V
0  |I|  4 mA 3000 V
