Chapter 5 107

Replaceable Parts

Replaceable Parts List

5. Replaceable Parts

Right Side View

Figure 5-15 Right Side View

Table 5-14 Right Side View

Ref.

Desig.

Keysight Part

Number

Qty. Description

1 0515-0430 1 SCREW-MACH M3.0 x L6 PN T10

2 0515-0372 4 SCREW-MACH M3.0 x L8 PN T10

e5052bse1047
