Keysight E5052B - Replacement Procedure

Chapter 6 153
Replacement Procedure
A21 PCI DSP / A24 GPIB Card Replacement
6. Replacement Procedure
Figure 6-9 A21 PCI / A24 GPIB Card Removal
Replacement Procedure
Step 1. Replace the PCI / GPIB card by inverse procedure of removal.
NOTE Fasten the 5/8 inch nut (item 7) using a open-end torque wrench for replacement.
e5052bse1069
3 4
2
6
5
7
8
1
