182 Chapter 6
Replacement Procedure
A52 Inverter Assembly Replacement
A52 Inverter Assembly Replacement
Tools Required
• TORX screwdriver, T10, T15, and T20
• Open-end torque wrench, 5/16 inch (set to 1.02 N-m / 9.0 lb-in) (for reconnecting SMA
connector)
• Flat edge screwdriver
Removal Procedure
Refer to Figure 6-25 for this procedure.
Step 1. Remove the outer cover as described in “Outer Cover Removal” on page 136.
Step 2. Remove the front panel as described in “Front Panel Removal” on page 138.
Step 3. Remove the front panel cover as described in “Front Panel Cover Removal” on page 180.
Step 4. Disconnect the three cables (item 1) connected front panel keyboard.
NOTE Be careful to remove the cables (item 1), and not apply any scratches on the cables.
Step 5. Remove the two TORX T15 screws (item 2) fastening the inverter assembly.
Step 6. Disconnect the two cables (item 3) connected the inverter assembly.
