Overview
Instrument Option Descriptions
Instrument Option Descriptions
The UXA has a variety of hardware and measurement application options.
Several of these options are “standard” so they are automatically installed on
all UXA analyzers. All options require license files to be present in instrument
memory before the option can be used, or viewed on the Show, System screen.
From the front panel, press System, Show, System to view a list of all installed
options.
A current list of all instrument options and retrofit requirements is available on
the Keysight web site for the UXA signal analyzer.
Option Description Notes
508 3 Hz to 8.4 GHz frequency range
513 3 Hz to 13.6 GHz frequency range
526 3 Hz to 26.5 GHz frequency range
544 3 Hz to 44 GHz frequency range
550 3 Hz to 50 GHz frequency range
ALV Auxiliary Log Video (at rear panel Aux IF connector)
B25 25 MHz information bandwidth
B40 40 MHz information bandwidth in addition to 25 MHz BW
B2X 255 MHz information bandwidth
B5X 510 MHz information bandwidth
H1G 1 GHz information bandwidth Requires Option 550
CRP Arbitrary IF Output
(10 MHz to 75 MHz programmable, Aux IF connector on rear panel)
CR3 2nd IF Out (Aux IF connector on rear panel) Included on all units
C35 APC 3.5 mm Connector With Option 526 only
DP2 Deep Capture Memory for IQ data capture Included on all units
DP4 4 GB Capture Memory Requires Option B2X or B5X
EA3 Electronic Attenuator
EDP Enhanced Display Package Included on all units
EMC Software only. Provides EMI detectors and BWs.
EXM External Mixing Included on all units
FBP Full Bypass Path Requires Options 550 and
H1G
