Keysight Technologies N9040B UXA Signal Analyzer Service Guide 473
Assembly Replacement Procedures
Front Frame Assembly
Front Frame Assembly Components
Figure 15-117 Front Frame Parts
Access to any of the Front Frame assemblies requires removal of the Front Frame Assembly from
the chassis.
Item Description Item Description
7 A1A5 Controller Board 13 A1W2 Cable
8 A1W4 Cable 14 A1W3 Cable
9 A1W1 Cable 15 A1A4 Converter DC-DC
10 A1MP14 Front Panel Interface Bracket 16 W1 Cable
12 A1MP21 Display Bracket 17 W29 Semi-rigid Cable
