Page #520 background image
520 Keysight Technologies N9040B UXA Signal Analyzer Service Guide
Functional Tests
Frequency Response (Flatness)
Frequency Response (Flatness)
Test Limits
The frequency response test measures the signal analyzer’s amplitude error as
a function of the tuned frequency. Measurements are made ranging from
50 MHz to the maximum frequency range of your analyzer. The signal source
amplitude is measured with a power meter to eliminate error due to source
flatness. The measured value is normalized to 50 MHz.
Frequency Range Limit Relative to 50 MHz
20 Hz to 3.6 GHz ±1.5 dB
> 3.6 GHz to 8.4 GHz ±2.5 dB
> 8.4 GHz to 13.6 GHz ±3.0 dB
> 13.6 GHz to 26.5 GHz ±3.5 dB
Item
Critical Specifications
(for this test)
Recommended
Keysight Model
Adapter
Type N (m) to 3.5 mm (m)
Frequency: 10 MHz to 18 GHz
VSWR: < 1.1:1
1250-1743
Adapter,
3.5 mm (f) to 3.5 mm (f)
Frequency: 10 MHz to 26.5 GHz
VSWR: < 1.1:1
83059B
Cable, 3.5 mm, 1 meter
(Opt 508, 513, 526)
Frequency: 10 MHz to 26.5 GHz
VSWR: < 1.4:1
11500E
Cables, BNC
120 cm
Frequency: 10 MHz 10503A
Power Meter Compatible with power sensor E4418B
Power Sensor
(Opt 508, 513, 526)
Frequency Range: 50 MHz to 26.5 GHz 8485A
Power Splitter
(Opt 508, 513, 526)
Frequency Range: 50 MHz to 26.5 GHz
Tracking between ports: < 0.25 dB
11667B
Synthesized Sweeper
Frequency Range: 50 MHz to 50 GHz
a
PSG
a. Maximum frequency of the sweeper must be greater than or equal to maximum specified fre-
quency of the UXA.
