237
Keysight Technologies
N9040B UXA Signal Analyzer
Service Guide
11 Hardware Options
What You Will Find in This Chapter
The following information is found in this chapter.
A21 Wideband Analog IF Troubleshooting on page 239
A22 Wideband Digital IF Troubleshooting on page 245
Option RTS, Real-Time I/Q Data Streaming on page 246
Option H1G, 1 GHz Analysis Bandwidth Assembly on page 248
The UXA signal analyzer has a variety of hardware options that can be
purchased and installed at the time of new instrument sale, or as a post-sale
upgrade. Some of these hardware options require the installation of additional
hardware, and others require licensing hardware already present in the
standard instrument hardware configuration.
A current list of all instrument options and retrofit requirements is available on
the Keysight web site for the UXA signal analyzer at:
http://www.keysight.com/find/UXA_upgrades
Table 11-1 Hardware Options
Option Description Additional Hardware or
License Only
Service Guide Section
ALV Auxiliary Log Video
(at rear panel Aux IF connector)
License Only Chapter 5, “Front
End Control
Troubleshooting.”
B25 25 MHz Analysis Bandwidth path License Only Chapter 6,
“Analog/Digital IF
Troubleshooting.”
B40 40 MHz Analysis Bandwidth path in
addition to 25 MHz BW
License Only Chapter 6,
“Analog/Digital IF
Troubleshooting.”
B2X 255 MHz Analysis Bandwidth path Additional hardware This chapter
