238 Keysight Technologies N9040B UXA Signal Analyzer Service Guide
Hardware Options
What You Will Find in This Chapter
B5X 510 MHz Analysis Bandwidth path Additional hardware This chapter
CRP Arbitrary IF Output
(10 MHz to 75 MHz programmable, Aux
IF connector on rear panel).
License Only Chapter 5, “Front
End Control
Troubleshooting.”
EA3 Electronic Attenuator License Only Chapter 4, “RF
Section
Troubleshooting
(RF/Microwave
Analyzers).”
H1G 1 GHz Analysis Bandwidth Additional hardware This chapter
P08
P13
P26
P44
P50
Preamp, 100 kHz to 8.4 GHz
Preamp, 100 kHz to 13.6 GHz
Preamp, 100 kHz to 26.5 GHz
Preamp, 100 kHz to 44 GHz
Preamp, 100 kHz to 50 GHz
License Only Chapter 4, “RF
Section
Troubleshooting
(RF/Microwave
Analyzers).”
RTS Real-Time I/Q Data Streaming License and additional hardware This chapter
YAV Y-Axis Output License Only Chapter 6,
“Analog/Digital IF
Troubleshooting.”
See Chapter 12, “Block Diagrams.” for information on how these hardware options are
installed in the signal path.
Table 11-1 Hardware Options
Option Description Additional Hardware or
License Only
Service Guide Section
