347
Keysight Technologies
N9040B UXA Signal Analyzer
Service Guide
15 Assembly Replacement Procedures
What You Will Find in This Chapter
Procedures in this chapter enable you to locate, remove, and replace the
following major assemblies in your instrument.
Refer to Chapter 14, “Replaceable Parts.” for part numbers, assembly
descriptions, and ordering information.
Instrument Outer Case on page 352
Top Brace and Card Cage Brace on page 354
RF Area - Options 508, 513, 526 on page 358
A9 & A10 RF Attenuators on page 361
A11 Low Band Switch on page 365
A12 YTF Preselector on page 367
A20 YTO on page 370
Low Noise Path and Microwave Preselector Bypass Switches on
page 371
A13 RF Front End Assembly on page 381
RF Area - Options 544, 550 on page 388
A9 & A10 RF Attenuators on page 390
A11 Low Band Switch on page 393
A12 YTF Preselector on page 395
A20 YTO on page 398
Transfer Switches on page 399
A13 RF Front End Assembly on page 406
Card Cage Boards on page 413
A15 Front End Control on page 414
A16 Reference Assembly on page 415
