Keysight Technologies N9040B UXA Signal Analyzer Service Guide 295
Replaceable Parts
W53 Cable, Semi-rigid, SW3 port 2, Transfer Switch to SW1 port C, Coaxial Switch
(Options 508, 513, 526)
N9040-20029
W54 Cable, Semi-rigid, SW3 port 3, Transfer Switch to A11J3, Low Band Switch
Options 508, 513, 526
Options 544, 550
N9040-20030
N9040-20107
W55 Cable, Ribbon, SW3, Transfer Switch to A15J802, Front End Controller N9040-60038
W56 Cable, Ribbon, A21J23, Wideband Analog I.F. Assembly to Interconnect Bracket WBDIF
(Options B2X and B5X)
N9040-60042
W57 Cable, Ribbon, WBDIF Interconnect Bracket to A22J778, Wideband Digital I.F.
(Option B2X)
N9040-60045
Cable, Ribbon, WBDIF A22J778 to WBDIF A21J778 to WBDIF Interconnect Bracket
(Option B5X)
N9040-60041
W58 Cable, Semi-rigid, A13A2J3, Switched Filter Assembly to A13A2J4, Switched Filter
Assembly
N9020-20080
W59 Cable, Semi-rigid, SW4 Port 2, Coaxial Switch to A13A2J2, R.F. Front End Assembly
(Option B5X)
N9020-20267
W60 Cable, Semi-rigid, SW4 Port 1, Coaxial Switch to FL2 Bandpass Filter In (Option B5X) N9020-20268
W61 Cable, Semi-rigid, FL2, Bandpass Filter Out to SW5 Port 1, Coaxial Switch (Option B5X) N9020-20269
W62 Cable, Semi-rigid, SW5 Port 2, Coaxial Switch to A13A2J5 R.F. Front End Assembly
(Option B5X)
N9020-20264
W63 Cable, Semi-rigid, SW5 Port C, Coaxial Switch to A13A1J11, R.F. Front End Assembly
Option B5X, with freq Options 508, 513 or 526
Option B5X, with freq Options 544 or 550
N9020-20265
N9020-20276
W64 Cable, Semi-rigid, A13A1J10, R.F. Front End Assembly to SW4 Port C, Coaxial Switch
(Option B5X)
N9020-20266
W65 Cable, Semi-rigid, A13A1J3, R.F. Front End Assembly to A13A2J6 part of
A13 Assembly
W66 Cable, Semi-rigid, Switch 3, port 2 to Switch 6 port 1(Options 544, 550) N9040-20105
W67 Cable, Semi-rigid, Switch 6, port 4 to A12 YTF input (Options 544, 550) N9040-20109
W68 Cable, Semi-rigid, Switch 6, port 3 to A12 YTF output (Options 544, 550) N9040-20110
W69 Cable, Semi-rigid, Switch 6, port 2 to A13A1J9 (Options 544, 550) N9040-20111
W70 Cable Assembly (flex circuit), A22 WBDIF J9000 to A28 WBDIF Extension Board J1
(Option RTS with Option B2X)
N9040-60047
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
