298 Chapter 14 Replaceable Parts Replaceable Parts
Digital I.F. Board Plate Digital I.F. Board 8 2190-0068 Washers n/a n/a
8 2950-0054 Nuts 5/8-inch
socket
21 inch-lbs
Digital I.F. Board Plate Digital I.F. Board Plate
LVDS Connector
2 0515-1940 M3 X 0.45
(6 mm long)
Torx T-8 6 inch-lbs
Display Display Bracket 4 0515-1946 M3 X 0.5
(6 mm long)
Torx T-10 6 inch-lbs
Display Bracket Front Frame 6 0515-1946 M3 X 0.5
(6 mm long)
Torx T-10 6 inch-lbs
Disk Drive Disk Drive Tray 4 0515-1035 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
"Ext Mixer" Connector Front Frame 1 2950-0223 Hex Nut n/a 21 inch-lbs
External Reference BNC Rear Panel 1 2190-0102 Lock Washer n/a n/a
1 0590-2332 Hex Nut 9/16” Nut
Driver
21 inch-lbs
Fan Grill Fan Bracket (Right) 3 per 0515-1038 M3 X 0.5
(35 mm long)
Torx T-10 9 inch-lbs
Fan/Bracket Assembly Chassis (Left) 5 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Frame Assembly Chassis 14 0515-2044 M4 X 0.7
(10 mm long)
Torx T-20 21 inch-lbs
1 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Frame Cover Plate Front Frame 2 0515-1946 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
Table 14-2 Attaching Hardware
