Keysight N9040B Option 508 User Manual

Chapter 14 297
Replaceable Parts
Replaceable Parts
Table 14-2 Attaching Hardware
Attach To Qty Part Number Type Tool Torque
Analog IF Digital IF 3 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Attenuators Attenuator Bracket 2 per 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Attenuator Bracket Chassis 2 per 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Chassis Base Stiffener
(Covers A3, Digital I.F. Assembly)
Chassis Base 6 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
2 0515-1946 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
Chassis Bottom Chassis Side Brackets
(Left & Right)
13 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Chassis Front Brace Chassis Side Brackets
(Left & Right) & Chassis Bottom
9 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Chassis Front Bracket
(Inner/Bottom)
Chassis Front Bracket 6 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Chassis Side
(Right)
Chassis Side
(Inside Right)
1 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Coax Switch Coax Switch Bracket 2 0515-1946 M3 X 0.5
(6 mm long)
Torx T-10 6 inch-lbs
CPU Assembly Chassis 6 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
DC-DC Converter Display Bracket 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
