32 Keysight Technologies N9040B UXA Signal Analyzer Service Guide
Overview
Service Equipment You Will Need
20 dB Fixed Attenuator
(for Option EXM only)
8493C (Option 020) P
30 dB Fixed Attenuator
(for use with low-power power
sensors)
11708A P
Terminations
Type-N (m)
(for Option 508, 513)
909A (Option 012) P, T
3.5 mm (f)
(for Option 526)
909D (Option 526) P, T
BNC (m) 1250-0207 11593A P, T
Miscellaneous Devices
RF Power Splitter,
Type-N (f) connector
11667A P
Microwave Power Splitter,
3.5 mm (f) connector
11667B P
Directional Bridge,
Type-N (f) connector
86205A P
Directional Coupler,
SMA (f) connector
87300C P
Microwave Power Divider,
3.5 mm (f) connector
11636B P
Cables
Coaxial Cable,
3.5 mm (m) to 3.5 mm (m)
(2 required)
11500E 8120-4921 P
Type-N
precision Type-N (m) both ends
(2 required)
11500C P, T
BNC 50 Ω Coaxial,
BNC (m) both ends
(3 required)
10503A P, T
Filters
50 MHz Low Pass,
BNC (m) to BNC (f)
Telonic Berkeley TLA 50-5AB2 0955-0306 P, T
Table 1-1 Required Test Equipment
Instrument
Recommended Model
a
Alternative Model
a
Use
b
To Next Page
