KI Unite Panel System - Page 7

Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
7
Unite
®
Panel System - Panel Frame Assembly
Assembly Instructions
uppermost
hole
lowest
hole
beltline
hole
31
/ -16 x 1 /
bolt & flat washer
84
”
panel
frame
120
connector
block
°
120
light
shield
°
height-adjustable
glide
Figure 7 - 3-
Way 120 , Corner Intersection°
Detail D
120°
connector
block hole
120
connector
block
°
120
light
shield
°
