Matrix 2360 Programmable Shear User Manual - Section 5
12-092600 A 35
6. Enter the size and quantity of strips by touching the UNITS button. This
opens the Set Units Screen (see Section 5.3.3). Set the values by pressing
the value field desired and, using the arrow buttons, change to the value
desired. If an incorrect value is entered, press ESCAPE to return to the
previously saved value. Press RETURN to return to the Main Control Screen.
7. Now press the OPTIONS button. On the Options Screen, choose either
CLEAR SCRAP ON or OFF. If the Feature Registration Option was
purchased, press the FEATURE SENSOR button and follow step 8. If the
option was not purchased, go to step 9.
8. At the Set Sensor Screen, follow the instructions for setting the sensor in
section 6.3.2. When the sensor is set, return to the Main Screen.
9. Press the BLADE DOWN button on the Main screen.
10. Now feed the material to be cut under the pinch roller (lifting the top roller by
pressing and holding down the tension adjustment knob) and push the
material up to the lowered blade. Release the tension adjustment knob.
11. Press the BLADE UP button.
12. Press the CUT 1 STRIP button on the touch screen to cut off the leading
edge. Discard this piece.
13. Press CYCLE to cut at least ten sample strips. (The number of strips cut was
set in 6.)
NOTE: If the Feature Registration Option was purchased, the correct
factory setting of the strip width tested with the material provided to
Kinematic prior to delivery is recorded on the STRIP WIDTH field of the
C2360 Feature Registration / Micrometer Setting Sheet provided with
the unit.
This strip width should be less than the actual pitch between features on the
input material, so that the motor slows just before the feature is detected.
NOTE: When setting the strip quantity (QTY.), set to a number that
will leave at least 19 mm (.75”) of material at the trailing end of each
card. The blade will cut accurately only when at least 19 mm (.75”) of
material is left behind the blade as scrap. If less material is left, the
rollers are not holding the material securely and precise strips cannot
be cut.
