Matrix 2360 Programmable Shear User Manual - Section 5
36 12-092600 A
14. Using a calibrated set of outside calipers, measure the cut strips and write
down the measured average. If the cuts are within tolerance, continue with
15. If the average is out of tolerance, troubleshoot the problem with these
suggestions:
a. Make sure that the material is moving freely between the guide rails. See
Section 5.4.1.
b. Test the pinch roller pressure. See Section 5.4.2.
c. If the Feature Registration Option was purchased, strip width should be
less than the actual pitch between features on the input material.
d. If the strips are still out of tolerance see section 5.4.3 to adjust the offset.
15. If desired, press the CYCLE pushbutton to cut the remainder of the card into
strips.
16. If some scrap card material remains behind the blade after a cycle, it can be
pushed through to the output chute with the CLEAR SCRAP button on the
main screen.
17. Set the strip quantity to the production cycle number of strips. (See 6.)
Production Steps:
Insert material and keep repeating loading material (execute 9, 10, 11, and 12), then
press CYCLE to cut the programmed number of strips, and (if CLEAR SCRAP is not
ON) finally press CLEAR SCRAP to eject the trailing edge.
