Kohler KDI 1903M Workshop Manual

9
ASSEMBLY INFORMATION
EN 138
Waste line fastening drilled capscrew on injectors M10x1 15
Injector side injection tube nuts M12x1.5 25
Injection pump side injection tubes nuts M12x1.5 25
Injection pump fastening capscrew M8x1.25 25
Loctite
2701*
Fuel injection pump locking screw
...
Fuel delivery fastening drilled capscrew (on injection pump)
M10x1
25
Waste line fastening drilled capscrew (on injection pump)
M10x1
25
Bleeding screw injection pump (on waste line fastening
drilled capscrew)
M6x1 22
Fuel filter fastening capscrew
M8x1.25
22
INTAKE MANIFOLD
Component
Thread
(mm)
Torque (Nm) Sealer
Fastening screw intake manifold
M8x1.25
25
Intake flange fastening capscrew
M8x1.25
25
EXHAUST MANIFOLD
Component
Thread
(mm)
Torque (Nm) Sealer
Exhaust manifold fixing stud
M8x1.25
25
Exhaust manifold fixing nut
M8x1.25
25
Exhaust flange/muffler fixing nut M8x1.25 25
LUBRICATION CIRCUIT
Component
Thread
(mm)
Torque (Nm) Sealer
Oil filter fastening union M20x1.5 15
Loctite
2701*
Oil filter
M20x1.5
15
Oil pump carter fastening capscrew
TG6
10
Carter distribution fastening capscrew
M8x1.25
25
Fastening capscrew for plug on timing system cover
TG6
10
Side oil load flange fastening capscrew (onto carter
distribution)
TG6 10
Pressure relief valve cap
M16x1.5
50
Breather system cover fastening capscrew (on rocker arms
cover)
M8x1.25 25
CRANKSHAFT PULLEY
Component
Thread
(mm)
Torque (Nm) Sealer
Crankshaft pulley fastening screw
M16x1.5
360
Molyslip
COOLANT CIRCUIT
