Kohler KDI 1903M Workshop Manual

ASSEMBLY INFORMATION
9
139
EN
Component
Thread
(mm)
Torque (Nm) Sealer
Thermostatic valve cover fastening capscrew M6x1 10
Coolant pump fastening capscrew M8x1.25 25
ELECTRICAL COMPONENTS
Component
Thread
(mm)
Torque (Nm) Sealer
Coolant temperature sensor
M12x1.5
20 max.
Oil pressure switch
M12x1.5
35
Sensor for water presence in fuel
5
Alternator bracket fastening capscrew
M8x1.25
25
Alternator fastening capscrew
M8x1.25
40
Alternator fastening capscrew
M10x1.5
69
Starter motor fastening capscrew
M10x1.5
45
Supply cable fastening nut (starter motor)
M8x1.25
10
CONTROLS
Component
Thread
(mm)
Torque (Nm) Sealer
Accelerator bracket fastening capscrew
M6x1
10
* Alternatively to the capscrew replacements, with "Dri-loc"
OPTIONAL COMPONENTS (CAP. 11)
OIL DIPSTICK ON CYLINDER HEAD
Component
Thread (mm)
Torque (Nm)
Sealer
Oil dipstick tube fastening capscrew
M6x1
10
HEATER
Component
Thread (mm)
Torque (Nm)
Sealer
Flange intake with heater fastening capscrew
M8x1.25
25
ALTERNATOR WITH POLY-V BELT
Component
Thread (mm)
Torque (Nm)
Sealer
Pulley fastening capscrew
M10x1.5
48
Pulley positioning blocking nut capscrew
M10x1.5
45
Alternator brace fastening capscrew
M8x1.25
25
Alternator fastening capscrew (upper)
M8x1.25
25
Alternator fastening capscrew (lower) M8x1.25 40
Pulley sliding plate fastening capscrew
M8x1.25
25
IDLE GEAR (FOR 3th /4th PTO)
Component
Thread (mm)
Torque (Nm)
Sealer
Gear drilled fastening capscrew M14x1.5 Molyslip
3
a
PTO
