Kohler KDI 1903M Workshop Manual

9
ASSEMBLY INFORMATION
EN 140
Component
Thread (mm)
Torque (Nm)
Sealer
Pump support fastening capscrew
M8x1.25
25
Loctite 2701*
Pump fastening capscrew
M8x1.25
25
4
a
PTO
Component
Thread (mm)
Torque (Nm)
Sealer
Grooved crankshaft support fastening capscrew
M8x1.25
25
Loctite 2701*
Cover fastening capscrew (3rd PTO side)
M8x1.25
25
Sump support fastening capscrew
TG6
10
Pump fastening capscrew
M8x1.25
25
BALANCE SHAFTS (4 CYLINDERS)
Component
Thread (mm)
Torque (Nm)
Sealer
Housing closing panel fastening capscrew
M6x1
8
Shafts support fastening capscrew
M10x1.5
50
REMOTE OIL FILTER
Component
Thread (mm)
Torque (Nm)
Sealer
Head fixing joint on crankcase
M20x1.5
25
Loctite 2701
Crankcase head nipple and oil filter support
M14x1.5
40
Tube union on crankcase head
G3/8
30
Tube union on filter support G3/8 35
Oil filter M20x1.5 20
Filter support head air bleeding cap
M8x1.25
25
INTAKE CIRCUIT
Component
Thread (mm)
Torque (Nm)
Sealer
Air filter support plate fastening capscrew (on flange bell)
M8x1.25
25
Air filter support fastening capscrew
M8x1.25
25
EXHAUST CIRCUIT
Component
Thread (mm)
Torque (Nm)
Sealer
Muffler brace support fastening capscrew
M8x1.25
25
Muffler fastening capscrew on muffler
M8x1.25
25
Muffler fastening nut
M8x1.25
25
COOLING CIRCUIT
Component
Thread (mm)
Torque (Nm)
Sealer
Blower fastening capscrew
M6x1
10
Radiator support fastening capscrew
M16x1.5
150
Shroud radiator fastening capscrew
M6x1
10
Radiator lower brace fastening capscrew
M8x1.25
25
Radiator on anti-vibrating
M8x1.25
25
Vibration-damping nut fixing (on radiator support)
M8x1.25
25
Anti-vibrating and brace fastening capscrew (upper)
M6x1
10
