INFORMATION FOR DISASSEMBLY
7
77
EN
•
The belt must always be replaced every time it is
disassembled, even if it has not reached th
e
s
cheduled hours for replacement
4.
Undo the screws C and D and remove th
e
a
lternator
E.
7.2.4 Sensors and switches
Important
•
After disassembly, protect the sensors suitabl
y
a
gainst knocks, dampness and any hig
h
temperature sources.
•
The sensors and switches cannot be repaired,
therefore they must be replaced in the event o
f
an
omalies.
7.2.4.1 Oil pressure switch disassembly ( )
1.
Unscrew and remove oil pressure switch H.
Fig 7.3
7.2.4.2 Coolant temperature sensor ( )
1.
Unscrew and remove the sensor L.
Fig 7.4
