Kohler KDI 1903M Workshop Manual

7
INFORMATION FOR DISASSEMBLY
EN 92
7.13.5.1 Rings ( )
1.
Remove the seal rings S.
Fig 7.53
7.13.6 Breather room closing cover ( )
1.
Undo the screws AE and remove the cover AF.
Fig 7.54
7.13.7 Camshaft
1.
Remove the retainer ring V.
2.
Extract the camshaft W from the upper crankcas
e
AB.
Fig 7.55
7.13.8 Camshaft tappets
1.
With a magnet, remove the tappets AA from the
upper semi-crankcase AB.
Fig 7.56
