(7) Air flow sensor (19) Accel sensor 1 (31) Neutral switch
(8) Intake throttle valve (20) Accel sensor 2 (32)
Exhaust gas temperature sensor
(T0)
(9) Starter relay (21) Vehicle speed sensor (33)
Exhaust gas temperature sensor
(T1)
(10) Battery (22) Differential pressure sensor (ΔP) (34)
Exhaust gas temperature sensor
(T2)
(11) Glow relay (23) Suction control valve (SCV)
(12) Glow heater (24) Coolant temperature sensor
* Injector 4 is equipped only V2403 model.
