Kubota D1803-CR-E4 - Replacing Fuel Hose and Clamps; Replacing Intake Air Line

11.10 Replacing fuel hose and
clamps
1. Loosen the clamp (2) and remove the fuel hose (1).
(1) Fuel hose (2) Clamp
2. Replace
the
fuel hose (1) and clamp (2) with new
ones.
3. Tighten the clamp (2) correctly.
4. After you replace the fuel hose and the clamp,
bleed the fuel system.
11.11 Replacing intake air line
IMPORTANT
• To
prevent serious damage to the engine, keep
out dust in the intake air line.
1. Loosen the clamp (2).
2. Remove the intake air hose (1) and clamp (2).
(1) Intake air hose (2) Clamp
3. Replace
the
intake air hose (1) and clamp (2) with
new ones.
4. Tighten the clamp (2) correctly.
CHECK AND MAINTENANCE
11.Check points of every 2 years 3. MAINTENANCE
D1803-CR-E4,D1803-CR-TE4,D1803-CR-TIE4,V2403-CR-E4,V2403-CR-TE4,V2403-CR-TE4BG,V2403-CR-TIE4
3-31
KiSC issued 12, 2018 A
