A 60 mm (2.4 in.)
B 45 mm (1.8 in.)
C 37.3 mm (1.47 in.)
D 35 mm (1.4 in.)
E 12 mm dia. (0.47 in. dia.)
F 10 mm dia. (0.39 in. dia.)
G
20.34 to 20.50 mm dia. (0.8008 to
0.8070 in. dia.)
H 1.0 rad (60°)
C1 Chamfer 1.0 mm (0.039 in.)
Material SS400
SPECIAL TOOLS
2. GENERAL
D1803-CR-E4,D1803-CR-TE4,D1803-CR-TIE4,V2403-CR-E4,V2403-CR-TE4,V2403-CR-TE4BG,V2403-CR-TIE4
