Kubota D1803-CR-E4 - Page 65

I 100 mm (3.94 in.)
J M8 × Pitch 1.25
K 0.70 rad (40°)
L 129 mm dia. (5.08 in. dia.)
M 31.950 to 31.975 mm dia. (1.2579 to 1.2588 in. dia.)
N 22 mm dia. (0.87 in. dia.)
O 145 mm dia. (5.71 in. dia.)
P 90 mm (3.5 in.)
Q 12 mm (0.47 in.)
C0.3 Chamfer 0.3 mm (0.01 in.)
C1 Chamfer 1.0 mm (0.039 in.)
C2 Chamfer 2.0 mm (0.079 in.)
C4 Chamfer 4.0 mm (0.16 in.)
Material SS400
