Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-4
0511 Multiple sheets of jam The registration sensor 1 (RS1)*1 or registration
sensor 3 (RS3)*2 does not turn off during paper
feed from cassette 1.
H
0512 PF feed sensor 1 (PFFS1) does not turn off dur-
ing paper feed from cassette 2.
2
0513 PF feed sensor 2 (PFFS2) does not turn off dur-
ing paper feed from cassette 3.
3
0514 PF feed sensor 3 (PFFS3) does not turn off dur-
ing paper feed from cassette 4.
4
0515 PF feed sensor 4 (PFFS4) does not turn off dur-
ing paper feed from cassette 5.
5
0518 The registration sensor 1 (RS1)*1 or registration
sensor 3 (RS3)*2 does not turn off during paper
feed from duplex section.
H
0519 The registration sensor 1 (RS1)*1 or registration
sensor 3 (RS3)*2 does not turn off during paper
feed from MP tray.
H
1403 PF feed sensor 2 non arrival
jam
PF feed sensor 2 (PFFS2) does not turn on dur-
ing paper feed from cassette 3.
3
1404 PF feed sensor 2 (PFFS2) does not turn on dur-
ing paper feed from cassette 4.
4
1405 PF feed sensor 2 (PFPFS2) does not turn on dur-
ing paper feed from cassette 5.
5
1413 PF feed sensor 2 stay jam PF feed sensor 2 (PFFS2) does not turn off dur-
ing paper feed from cassette 3.
2
1414 PF feed sensor 2 (PFFS2) does not turn off dur-
ing paper feed from cassette 4.
2
1415 PF feed sensor 2 (PFFS2) does not turn off dur-
ing paper feed from cassette 5.
2
1604 PF feed sensor 3 non arrival
jam
PF feed sensor 3 (PFFS3) does not turn on dur-
ing paper feed from cassette 4.
4
1605 PF feed sensor 3 (PFFS3) does not turn on dur-
ing paper feed from cassette 5.
5
1614 PF feed sensor 3 stay jam PF feed sensor 3 (PFFS3) does not turn off dur-
ing paper feed from cassette 4.
3
1615 PF feed sensor 3 (PFFS3) does not turn off dur-
ing paper feed from cassette 5.
3
1805 PF feed sensor 4 non arrival
jam
PF feed sensor 4 (PFFS4) does not turn on dur-
ing paper feed from cassette 5.
5
1815 PF feed sensor 4 stay jam PF feed sensor 4 (PFFS4) does not turn off dur-
ing paper feed from cassette 5.
4
Code Contents Conditions
Jam
location*
