Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-5
4002 Registration sensor 1 or 3 non
arrival jam
The registration sensor 1 (RS1)*1 or registration
sensor 3 (RS3)*2 does not turn on during paper
feed from cassette 2.
1
4003 The registration sensor 1 (RS1)*1 or registration
sensor 3 (RS3)*2 does not turn on during paper
feed from cassette 3.
1
4004 The registration sensor 1 (RS1)*1 or registration
sensor 3 (RS3)*2 does not turn on during paper
feed from cassette 4.
1
4005 The registration sensor 1 (RS1)*1 or registration
sensor 3 (RS3)*2 does not turn on during paper
feed from cassette 5.
1
4012 Registration sensor 1 or 3
stay jam
The registration sensor 1 (RS1)*1 or registration
sensor 3 (RS3)*2 does not turn off during paper
feed from cassette 2.
H
4013 The registration sensor 1 (RS1)*1 or registration
sensor 3 (RS3)*2 does not turn off during paper
feed from cassette 3.
H
4014 The registration sensor 1 (RS1)*1 or registration
sensor 3 (RS3)*2 does not turn off during paper
feed from cassette 4.
H
4015 The registration sensor 1 (RS1)*1 or registration
sensor 3 (RS3)*2 does not turn off during paper
feed from cassette 5.
H
4101 Registration sensor 2 non
arrival jam *2
The registration sensor 2 (RS2) does not turn on
during paper feed from cassette 1.
H
4102 The registration sensor 2 (RS2) does not turn on
during paper feed from cassette 2.
H
4103 The registration sensor 2 (RS2) does not turn on
during paper feed from cassette 3.
H
4104 The registration sensor 2 (RS2) does not turn on
during paper feed from cassette 4.
H
4105 The registration sensor 2 (RS2) does not turn on
during paper feed from cassette 5.
H
4108 The registration sensor 2 (RS2) does not turn on
during paper feed from duplex section.
H
4109 The registration sensor 2 (RS2) does not turn on
during paper feed from MP tray.
H
Code Contents Conditions
Jam
location*

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
