Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-7
YC29
1 DEEP_SLEEP
N
O 0/3.3 V DC Sleep signal
Connected to
the connect
right PWB
2 RFANH O 0/24 V DC RFM: On/Off
3 MPFSOL O 0/24 V DC MPSOL: On/Off
4 COVOPN
5 LIFTMOTOR O 0/5 V DC LM: On/Off
6 RFANL O 0/24 V DC RFM: On/Off
7 DLPCL O 0/3.3 V DC DEVCL: On/Off
8 DHEATER_R
EM
O 0/24 V DC DH: On/Off
9 FEEDCL O 0/24 V DC PFCL: On/Off
10 POWERSW I 0/3.3 V DC PSSW: On/Off
11 REGCL O 0/24 V DC RCL: On/Off
12 CASSET O Analog CSSW: On/Off
13 PSLEEPN I 0/5 V DC Sleep mode signal
14 MMOTCWN O 0/5 V DC MM drive shift signal
15 RELAY I 0/5 V DC Relay control
16 MMOTRDYN I 0/3.3 V DC MM ready signal
17 ZCROSSN O 0/5 V DC(pulse) Zero crossing signal
18 MMOTON O 0/5 V DC MM: On/Off
19 HEAT1REM O 0/24 V DC Fuser heater control
20 TYPE - - Not used
21 GND - - Ground
22 MMOTCLK O 0/5 V DC(pulse) MM clock signal
23 *1 GND - - Ground
24 *1 DMOTCLK O 0/5 V DC(pulse) DRM clock signal
25 *1 GND - - Ground
26 *1 DMOTRDYN I 0/3.3 V DC DRM ready signal
27 *1 MIDCL O 0/24 V DC PCCL: On/Off
28 *1 DMOTON O 0/5 V DC DRM: On/Off
29 *1 DUCL O 0/24 V DC DUCL: On/Off
30 *1 HEAT2REM O 0/24 V DC Fuser heater control
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
