Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-8
YC30
1 AIRTEMP I Analog Temperature sensor input signal
Connected to
the key right
PWB *3
or
the opera-
tion panel
PWB *2
2 AIR WET I Analog Humid sensor input signal
3 GND - - Ground
4 WETCLK O 0/3.3 V DC (pulse) Humid sensor clock signal
YC31
1 GND - - Ground
Connected to
the devel-
oper fan
motor
2 +24V0_E3 O 24 V DC 24 V DC power output
YC1000
1 12V3 E2 O 12 V DC 12 V DC power output
Connected to
the CCD
PWB
2 12V3 E2 O 12 V DC 12 V DC power output
3N.C.
4 +5V3 E3 O 5 V DC 5 V DC power output
5 +5V3 E3 O 5 V DC 5 V DC power output
6 N.C. - - Not used
7 GND - - Ground
8 CCDOSR I Analog Image analog signal RED
9 GND - - Ground
10 CCDOSG(EV
EN)
I Analog Image analog signal GREEN
11 GND - - Ground
12 CCDOSB(OD
D)
I Analog Image analog signal BLUE
13 GND - - Ground
14 CCDSW O 0/3.3 V DC CCD color/BW change signal
15 CCDSH O 0/3.3 V DC Shift gate signal
16 GND - - Ground
17 GND - - Ground
18 CCDPH1+ O LVDS CCD shift register clock signal
19 CCDPH1- O LVDS CCD shift register clock signal
20 GND - - Ground
21 CCDCP- O LVDS CCD clamp signal
22 CCDCP+ O LVDS CCD clamp signal
23 GND - - Ground
24 CCDRS+ O LVDS CCD reset signal
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
