Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-10
YC1003
11 GND - - Ground
Connected to
the DP origi-
nal sensor,
theDP regist
sensor, DP
open/close
sensor, DP
switchback
sensor, DP
timing sensor
12 JHP_SW I 0/3.3 V DC DPSBS: On/Off
13 +3.3V3S O 3.3 V DC 3.3 V DC power output
14 GND - - Ground
15 TIMING_SW I 0/3.3 V DC DPTS: On/Off
YC2002 *3
1 GND - - Ground
Connected to
the opera-
tion panel
PWB
2 PANEL STA-
TUS
I 0/3.3 V DC Operation panel status signal
3INT
POWERKEY_
N
I 0/3.3 V DC Power key: On/Off
4 PANEL_RESE
T
O 0/3.3 V DC OPPWB-M reset signal
5 AUDIO O Analog Voice output signal
6 LIGHTOFF_P
OWERON
O 0/3.3 V DC Sleep return signal 1
7 SHUTDOWN O 0/3.3 V DC 24 V down signal
8 LED PRO-
CESSING N
O 0/3.3 V DC Processing LED control signal
9 LED ATTEN-
TION N
O 0/3.3 V DC Attention LED control signal
10 LED MEM-
ORY N
O 0/3.3 V DC Memory LED control signal
11 SUSPEND_P
OWER
O 5 V DC 5 V DC power output
12 ENERGY_SA
VE
O 0/3.3 V DC Energy save signal
13 BEEP_POWE
RON
O 0/3.3 V DC Sleep return signal 0
14 SECOND_TR
AY_SW
-- Not used
15 GND - - Ground
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
