Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-11
*1: 50/60 ppm model only
*2: Basic model only
*3: HyPAS model only
YC2002 *2
1 GND - - Ground
Connected to
the opera-
tion panel
PWB
2- -- Not used
3INT_POWER
KEY_N
I 0/3.3 V DC Power key: On/Off
4 FPRST O 0/3.3 V DC Panel reset signal
5 AUDIO O Analog Voice output signal
6- -- Not used
7 PAN_TXD O 0/3.3 V DC Serial comunication data signal
8 PAN_RXD I 0/3.3 V DC Serial comunication data signal
9- -- Not used
10 - - - Not used
11 5.0V2_C O 5 V DC 5 V DC power output
12 - - - Not used
13 LCDCON O 0/3.3 V DC LCD control signal
14 3.3V1_C O 0/3.3 V DC 3.3 V DC power output
15 GND - - Ground
YC2003 *3
1 +5V0 PANEL O 5 V DC 5 V DC power output
Connected to
the opera-
tion panel
PWB
2 +5V0 PANEL O 5 V DC 5 V DC power output
3 GND - - Ground
4 GND - - Ground
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
