Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-53
(3) Connector lists
Connector Pin Signal I/O Voltage Description
YC2
1 GND - - Ground
Connected to
the LCD
2 R0 O 0/3.3 V DC LCD Control signal
3 R1 O 0/3.3 V DC LCD Control signal
4 R2 O 0/3.3 V DC LCD Control signal
5 R3 O 0/3.3 V DC LCD Control signal
6 R4 O 0/3.3 V DC LCD Control signal
7 R5 O 0/3.3 V DC LCD Control signal
8 GND - - Ground
9 G0 O 0/3.3 V DC LCD Control signal
10 G1 O 0/3.3 V DC LCD Control signal
11 G2 O 0/3.3 V DC LCD Control signal
12 G3 O 0/3.3 V DC LCD Control signal
13 G4 O 0/3.3 V DC LCD Control signal
14 G5 O 0/3.3 V DC LCD Control signal
15 GND - - Ground
16 B0 O 0/3.3 V DC LCD Control signal
17 B1 O 0/3.3 V DC LCD Control signal
18 B2 O 0/3.3 V DC LCD Control signal
19 B3 O 0/3.3 V DC LCD Control signal
20 B4 O 0/3.3 V DC LCD Control signal
21 B5 O 0/3.3 V DC LCD Control signal
22 GND - - Ground
23 DCLK O 0/3.3 V DC LCD dot clock signal
24 3.3V O 3.3V DC 3.3 V DC power output
25 3.3V O 3.3V DC 3.3 V DC power output
26 3.3V O 3.3V DC 3.3 V DC power output
27 3.3V O 3.3V DC 3.3 V DC power output
28 DE O 0/3.3 V DC(pulse) LCD data enabling signal
29 HSYNC O 0/3.3 V DC(pulse) Horizontal synchronizing signal
30 VSYNC O 0/3.3 V DC(pulse) Vertical synchronizing signal
31 LED_EN O 0/3.3 V DC Backlight LED enabling signal
32 LED_PWM O 0/3.3 V DC Backlight LED control signal
33 TSC_INT - - Not used
34 I2C_SDA - - Not used
35 I2C_SCL - - Not used

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
