Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-54
YC6
1 GND - - Ground
Connected to
the control
PWB
2 SECOND_TR
AY_SW
I 0/3.3 V DC JEPS: On/Off
3 BEEP_POWE
RON
I 0/3.3 V DC Acknowledging beep restoration signal
4 ENERGY_SA
VE
I 0/3.3 V DC Energy save signal
5 SUSPEND_P
OWER
I 3.3V DC 3.3 V DC power input
6 LED MEM-
ORY N
I 0/3.3 V DC Memory LED control signal
7LED ATTEN-
TION N
I 0/3.3 V DC Attention LED control signal
8 LED PRO-
CESSING N
I 0/3.3 V DC Processing LED control signal
9 SHUTDOWN I 0/3.3 V DC 24 V down signal
10 LIGHTOFF_P
OWERON
I 0/3.3 V DC LCD power On/ Off signal
11 AUDIO I Analog Audio output signal
12 PANEL_RESE
T
I 0/3.3 V DC Reset signal
13 INT_POWER
KEY_N
O 0/3.3 V DC Power key: On/Off
14 PANEL STA-
TUS
O 0/3.3 V DC Operation panel status signal
15 GND - - Ground
YC7
1 GND - - Ground
Connected to
the key-left
PWB
2 SCAN0 O 0/3.3 V DC (pulse) Scan signal 0
3 KEYLEFT1 I 0/3.3 V DC (pulse) Operation panel key scan return signal 1
4 LEDLEFT1 O 0/3.3 V DC (pulse) Operation panel LED display drive
signal 1
5 KEYLEFT2 I 0/3.3 V DC (pulse) Operation panel key scan return signal 2
6 SCAN1 O 0/3.3 V DC (pulse) Scan signal 1
7 SCAN2 O 0/3.3 V DC (pulse) Scan signal 2
8 SCAN3 O 0/3.3 V DC (pulse) Scan signal 3
9 KEYLEFT0 I 0/3.3 V DC (pulse) Operation panel key scan return signal 0
10 LEDLEFT0 O 0/3.3 V DC (pulse) Operation panel LED display drive
signal 0
11 LEDLEFT2 O 0/3.3 V DC (pulse) Operation panel LED display drive
signal 2
12 S LED O 0/3.3 V DC Memory LED control signal
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
