2NM/2NX/2NY/2NZ/2P0/2P6
1-3-26
5. Change the setting value using the cursor right/left keys or numeric keys.
For output example 1, increase the value. For output example 2, decrease the value.
6. Press the start key. The value is set.
Caution
Check the copy image after the adjustment. If the image is still incorrect, perform the following
adjustments in maintenance mode.
U034 -------- U067 -------- U072
(P.1-3-30) (P.1-3-35)
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Center line of printing
(within ± 2.0 mm)
Correct image
Output
example 1
Output
example 2
To Next Page
