Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
1-3-71
U670 Outputting lists
Description
Outputs a list of data regarding fax transmissions.
Printing a list is disabled either when a job is remaining in the buffer or when [Pause All Print
Jobs] is pressed to halt printing.
Purpose
To check conditions of use, settings and transmission procedures of the fax.
Method
1. Press the start key.
2. Select the item to be output using the cursor up/down keys.
3. Press the start key. The selected list is output.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Sys Conf Report Outputs a list of software switches, self telephone number,
confidential boxes, ROM versions and other information.
Action List Outputs a list of error history, transmission line details and
other information.
Self Sts Report Outputs a list of settings in maintenance mode (own-status
report) regarding fax transmission only.
Protocol List Outputs a list of transmission procedures.
Error List Outputs a list of error.
Addr List(No.) Outputs address book in order IDs were added
Addr List(Idx) Outputs address book in order of names
One-touch List Outputs a list of one-touch.
Group List Outputs a list of group.

Kyocera Ecosys M6526cdn Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Functions	Print, Copy, Scan, Fax
Fax Speed	33.6 kbps
Mobile Printing Support	Yes
Paper Output Capacity	150 sheets
Max Paper Size	A4
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Connectivity	USB 2.0, Ethernet
Warm-up Time	29 seconds
Duty Cycle	50, 000 pages per month
Recommended Monthly Print Volume	Up to 3, 000 pages
First Copy Out Time	10 seconds
Zoom Range	25% - 400%
Scan to	Email, FTP, SMB, USB
Fax Resolution	300 x 300 dpi
Memory	512 MB
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
