2PV/2PW
1-4-2
(2) Paper misfeed detection condition
Figure 1-4-2 Paper jam location
Document
Processor
B
C
D
E
A
F
H
G
1
6
3
2
4
5
Sensors
Registration sensor
MP paper conveying
sensor
Eject sensor
PF feed sensor 1
PF feed sensor 2
DP timing sensor
1
2
3
4
5
6
Paper jam location
Cassette 1
MP tray
Machine inside
Fuser/Eject sections
Duplex section
Cassette 2
Cassette 3
Document processor
A
B
C
D
E
F
G
H
Machine
Paper feeder 1
Paper feeder 2
