2PV/2PW
1-3-80
U977 Data capture mode
Description
Store the print data sent to the machine into USB memory.
Purpose
In case to occur the error at printing, check the print data sent to the machine.
Method
1. Insert USB memory in USB memory slot.
2. Turn the main power switch on.
3. Enter the maintenance item.
4. Press the start key.
5. Select [Execute].
6. Press the start key.
7. Send the print data to the machine.
Once the print data is stored into USB memory, [OK] will be displayed.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U995 Memory data Individual setting
Description
Displays the memory data.
Purpose
This mode need not be executed. When the status report is output, the setting is displayed.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
To Next Page
