2PV/2PW
2-2-3
List of correspondences of PWB names
No. Name used in service manual Name used in parts list
1 Main PWB (MPWB) PARTS PWB MAIN ASSY SP
2 Engine PWB (EPWB) PARTS PWB ENGINE ASSY SP
3 Power source PWB (PSPWB) PARTS SWITCHING REGULATOR SP
4 High voltage PWB (HVPWB) PARTS HIGH VOLTAGE UNIT SP
5 Operation panel PWB (OPPWB) -
6 Relay PWB (RPWB) -
7 Drum relay PWB (DRRPWB) -
8 Eject PWB (EJPWB) PARTS PWB ASSY EXIT SP
9 Cassette PWB (CPWB) PARTS PWB ASSY CASSETTE SP
10 Drum PWB K (DRPWB-K) -
11 Drum PWB M (DRPWB-M) -
12 Drum PWB C (DRPWB-C) -
13 Drum PWB Y (DRPWB-Y) -
14 Developing PWB K (DEVPWB-K) -
15 Developing PWB M (DEVPWB-M) -
16 Developing PWB C (DEVPWB-C) -
17 Developing PWB Y (DEVPWB-Y) -
18 APC PWB K (APCPWB-K) -
19 APC PWB M (APCPWB-M) -
20 APC PWB C (APCPWB-C) -
21 APC PWB Y (APCPWB-Y) -
22 PD PWB K (PDPWB-K) -
23 PD PWB M (PDPWB-M) -
24 PD PWB C (PDPWB-C) -
25 PD PWB Y (PDPWB-Y) -
26 CCD PWB (CCDPWB) -
27 LED PWB (LEDPWB) -
28 LED driver PWB (LEDDRPWB) -
29 Fax control PWB (FCPWB) PARTS FAX UNIT J SP
