Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
1-3-93
Laser Scanner
Cleaning
Performing LSU cleaning
Description
The LSU cleaning motor drives the cleaning pad which in turn wipes clean the LSU dust
shield glass.
Purpose
To perform cleaning when the printed image is bad and stripes are seen in the vertical
direction.
Method
1. Enter the Service Setting menu.
2. Select [LaserScanner Cln] using the cursor up/down keys.
3. Press the start key.
4. Press [Yes] (the Left Select key). LSU cleaning is performed.
Completion
Press the stop key.
Drum surface
refreshing
Performing drum surface refreshing
Description
Rotates the drum approximately 2 minutes with toner lightly on the overall drum. The
cleaning blade in the drum unit scrapes toner off the drum surface to clean it.
Purpose
To clean the drum surface when image failure occurs due to the drum. This mode is
effective when dew condensation on the drum occurs.
Method
1. Enter the Service Setting menu.
2. Select [Drum Refresh] using the cursor up/down keys.
3. Press the start key.
4. Press [Yes] (the Left Select key). Drum surface refreshing is performed.
Completion
Press the stop key.
Service items Description

Kyocera Ecosys M6526cdn Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Functions	Print, Copy, Scan, Fax
Fax Speed	33.6 kbps
Mobile Printing Support	Yes
Paper Output Capacity	150 sheets
Max Paper Size	A4
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Connectivity	USB 2.0, Ethernet
Warm-up Time	29 seconds
Duty Cycle	50, 000 pages per month
Recommended Monthly Print Volume	Up to 3, 000 pages
First Copy Out Time	10 seconds
Zoom Range	25% - 400%
Scan to	Email, FTP, SMB, USB
Fax Resolution	300 x 300 dpi
Memory	512 MB
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
